| code |
WLL |
safety factor |
thread |
torque |
L1 |
S1 |
S2 |
A |
B |
C |
D |
E |
F |
G |
weight |
stock no. |
|
(kg) |
|
(mm) |
(Nm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(kg) |
|
| DSR M8 |
300 |
5 |
M8x1,25 |
6 |
14 |
8 |
16 |
33 |
30 |
30 |
38 |
27 |
14 |
53 |
0,30 |
1210082 |
| DSR M10 |
600 |
5 |
M10x1,50 |
10 |
17 |
8 |
16 |
33 |
30 |
30 |
38 |
27 |
14 |
53 |
0,30 |
1210083 |
| DSR M12 |
1000 |
5 |
M12x1,75 |
15 |
21 |
8 |
16 |
33 |
30 |
30 |
38 |
27 |
14 |
53 |
0,30 |
1210084 |
| DSR M16 |
1600 |
5 |
M16x2,00 |
50 |
27 |
8 |
20 |
45 |
42 |
45 |
54 |
38 |
17 |
76 |
0,90 |
1210085 |
| DSR M20 |
2500 |
5 |
M20x2,50 |
100 |
30 |
8 |
20 |
45 |
42 |
45 |
54 |
38 |
17 |
76 |
0,90 |
1210086 |
| DSR M24 |
4000 |
5 |
M24x3,00 |
160 |
36 |
14 |
24 |
62 |
55 |
60 |
83 |
55 |
25 |
117 |
2,60 |
1210087 |
| DSR M30 |
6300 |
5 |
M30x3,50 |
250 |
45 |
14 |
24 |
62 |
55 |
60 |
83 |
55 |
25 |
117 |
2,70 |
1210088 |
|
Other dimensions on request.
|
|
| kind of attachment |
 |
 |
 |
 |
 |
 |
| number of pieces |
1 |
2 |
1 |
2 |
2 |
2 |
4 |
4 |
| inclination angle |
0° |
0° |
90° |
90° |
45° |
60° |
45° |
60° |
| code |
WLL (kg) (safety factor = 4) |
| DSR M8 |
300 |
600 |
300 |
600 |
400 |
300 |
600 |
300 |
| DSR M10 |
600 |
1200 |
600 |
1200 |
800 |
600 |
1300 |
600 |
| DSR M12 |
1000 |
2000 |
1000 |
2000 |
1400 |
1000 |
2100 |
1000 |
| DSR M16 |
1600 |
3200 |
1600 |
3200 |
2200 |
1600 |
3400 |
1600 |
| DSR M20 |
2500 |
5000 |
2500 |
5000 |
3500 |
2500 |
5300 |
2500 |
| DSR M24 |
4000 |
8000 |
4000 |
8000 |
5600 |
4000 |
8400 |
4000 |
| DSR M30 |
6300 |
12500 |
6300 |
12600 |
8800 |
6300 |
13200 |
6300 |
In the case of an unsymmetrical load distriburion,
the lifting capacities applicable to the 2 and 3-/4-leg slings are the same as for 1-leg types at 0°.
|
